    High Transparency Thermoforming PET Sheet Plastic PET Folding Boxes

    Ask Lasest Price
    Brand Name : Jiaou
    Supply Ability : 30 Tons Per Day
    Price : Negociated
    Model Number : APET Sheet
    Certification : FDA, GRS, Reach, RoHS, ISO9001
    Payment Terms : T/T, L/C
    Delivery Time : To Be Negotiated
    • Product Details
    • Company Profile

    High Transparency Thermoforming PET Sheet Plastic PET Folding Boxes

    Thermoforming PET Sheet High Transparency

    Product Description


    Thermoforming PET sheet (polyethylene terephthalate) is a common thermoplastic that provides high dimensional stability, excellent mechanical strength and good resistance to creep. It offers resistance to chemicals, provides very low moisture absorption and is a good electrical insulator. PET sheet also performs well in wear applications and has a tough, hard surface that can be easily machined and polished.


    • Outstanding thermoforming characteristics, particularly in deep draw applications
    • Good impact resistance
    • Allows for rigid thermoforming cycle times
    • Die cuts/punches easily
    • Low forming temperature
    • Printable
    • Chemical resistant
    • Self-extinguishing


    Technical Data Sheet
    General PropertiesValueTest MethodUnit
    Density1.36ISO 1183g/cm³
    Water Absorption0.25ISO 62%
    FlammabilityHB / HBUL 94/
    Mechanical Properties
    Yield Stress85ASTM D638MPa
    Elongation @ Break15ASTM D638%
    Tensile Modulus of Elasticity3000ASTM D638MPa
    Notched Impact Strength (Charpy)2DIN EN ISO 179kJ/m2
    Ball Indentation Hardness170DIN EN ISO 2039-1MPa
    Shore Hardness84DIN EN ISO 868Scale D
    Thermal Properties
    Melting Temperature255ISO 11357-3°C
    Thermal Conductivity0.28DIN 52612-1W / (M*K)
    Thermal Capacity1.1DIN 52612kJ / (kg*K)
    Coefficient of Linear Thermal Expansion60DIN 5375210-6K-1
    Service Temperature, Long Term-20 up to +115Average°C
    Service Temperature, Short Term (Max.)180Average°C
    Heat Deflection Temperature80ASTM D648°C
    Electrical Properties
    Dielectric Constant3.4IEC 60250/
    Dielectric Dissipation Factor (50Hz)0.001IEC 60250/
    Volume Resistivity10 18IEC 60093Ω*cm
    Surface Resistivity10 16IEC 60093
    Comparative Tracking Index600IEC 60112
    Dielectric Strength20ASTM D149kV/mm

    Application For PET Sheet


    Thermoforming PET sheets are widely used for packaging consumer goods, electrical Accessories, and medical products. In packaging applications, PET sheet act as Excellent barriers to acids and strong oxidizers.


    Application

    - Packaging

    - Folding box

    - Vacuum therm-forming
    - Blister Pack


    High Transparency Thermoforming PET Sheet Plastic PET Folding Boxes

    High Transparency Thermoforming PET Sheet Plastic PET Folding Boxes


    Package & Delivery High Transparency Thermoforming PET Sheet Plastic PET Folding BoxesHigh Transparency Thermoforming PET Sheet Plastic PET Folding Boxes


    FAQ

    Q1. Are you a factory or trade company?

    A: We are a professional manufacturer with 15 years experience, if you have interests welcome to visit our factory.

    Q2. Do you provide samples? Is it free or extra?

    A: Yes, we could offer the sample for free, but charge by freight collection.

    Q3. How about the lead time?

    A: Normal sample supply it at once. Special samples need 3 days. mass production generally 5-10 working days after receiving your initial payment.

    Q4. Do you have any MOQ limit?

    A: Normal Only 1000kgs, Special colors about 5000kgs.

    Q5. What are your terms of payment?

    A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
